Author: Admin

Repair laser fibre ST600F – Another repair job completed

Admin
Melted Laser Fibre ST600DF for repair

Melted Laser Fibre ST600F for repair

Repair laser fibre ST600F

We receive many inquiries on laser fibre ST600F that is damaged after prolong use. Above is a Laser fibre ST600F 600 microns for repair. The connector in the above image is burnt by laser after prolong usage and require immediate service to replace the laser connector. In most common cases, the ends of the laser fibre has to be terminated, polished, cleaned and new connectors have to be fitted to the Laser fibre. We will also need to perform a general check to ensure that there is no other damage other than the laser burn on the ends.

Our company can offer free assessment and quotation for high power laser fibre delivery assemblies. As part of wear and tear after prolong use, laser fibre delivery assemblies are considered disposables and are not covered by most service contracts. In most instances, replacement of laser fibre assemblies are in the range of thousands and this would greatly impact on their overall cost of operations.

At Gold Technic, having your Laser fiber repaired will save you a lot of money and the repaired Laser fibre will last just as long as a new replacement. Our on site fibre repair team can offer quick turn around times to minimise downtime of your machine. A typical Laser fibre repair procedure typically takes about five to  ten days  depending on its complexity. Besides the D80 connectors, we can also custom the fibre termination with other types of connectors such as the SMA connectors.

Alexandrite rod repair refurbish recoat

Admin
Sample Alexandrite rod for repair recoat refurbish

Alexandrite rod for repair recoat refurbish

Alexandrite rods are used in Alexandrite lasers. It is a chromium-doped solid-state lasers based on the crystalline gain medium alexandrite, which is Cr3+:BeAl2O4. There are natural alexandrite gem stones, but material for laser crystals is artificially produced and grown in monocrystalline form with high crystal quality, using a modified Czochralski growth method. Among solid-state laser crystals, Alexandrite is the most suitable for a wide range of medical applications such as the lasing wavelength and tunability.

Alexandrite lasers is one of the most robust solid-state laser materials available with a thermal shock resistance five-times that of Nd:YAG.

Alexandrite’s combination of properties offer application in Medical / Aesthetic and other fields, in such areas as: dermatology, lithotripsy, dental, spectrosocopy, atmospheric lidar, testing of fiber optics and photodetectors, materials processing, pumping of dye lasers, non-linear optics studies and annealing of semiconductors.

Alexandrite rod Applications

Typical applications include laser-assisted hair removal, leg vein reduction and tatoos removal: as matter of fact Alexandrite is becoming the material of choice for a variety of aesthetic dermatology.

We are also providing servicing of Alexandrite rod of all sizes. Recently serviced rod for our customer using the Candela GentleLaser Laser Machine lowering their cost of operations. There are many reasons for Alexandrite rod breakdown in your laser machine. The rod may be broken due to mishandling or excessive water pressure build up or a leak in the laser chamber. Dust particles that has entered the chamber, the optics, or the rod itself can cause the  laser head rod to burn entirely over time.

After repair was done, our customer was able to get their Alexandrite rod working at a fraction of the price for a new replacement. The performance of the machine was as good as before.

The above rod can be used in Candela® GentleLaser series of machines

  • GentleLase
  • GentleLase plus
  • GentleLase  mini  MGL
  • Gentle MAX  GMAX
  • GentleLase Pro

We can also repair other models and sizes of Alexandrite rod.

Alexandrite rods Applications

AB Laser inc®, Baase®l Lasertechnik®, Cynosure®, Wavelength® and many more

Please feel free to email us or contact us at sales@goldtechnic.com for more detailed quote of your repair job.

Laser fiber repair| Mitsubishi ST600F fiber

Admin
Melted Sheathing of laser fiber assembly

Damaged Mitsubishi ST600F Laser Fiber

Do you have stock of broken or damaged laser fibers (E.g Mitsubishi ST600F) in your factory and do not know what to do with them? It is too expensive to clear out your store, knowing that you have spent thousands of dollars on your fibers.

We have the perfect solution for you.  Our laser fiber repair service can save you from spending on new fibers again. Whether it is a broken connector head, melted sheathing, loose connector, or missing connector, we can fulfill all requirements. These fibers can be refurbished and used again.  Send us a picture of your damaged fiber and we will be able to make a rough assessment via email.

All D80 type fiber connectors, Laser fiber cores (common sizes below) and sheathing are available on ex-stock basis. Turn around time for repairs as short as 2 work days. All laser fibers received by Gold Technic Laser will be subjected to a pre-inspection process to determine if repair is possible. If repair is not possible, we will advise the customer and offer a possible replacement. If repair is possible and approved by customer, the faulty laser fiber will go through a thorough 8 steps process as highlighted below:

  1. Inpection and determining of damage
  2. Repair of laser fiber damage / Replacement of damaged components
  3. Visual Inspection of repaired laser fiber assembly ( Fiber ends at 500x microscope, Laser fiber assembly components : Connectors, sheathing)
  4. Testing of fiber with our measuring equipment to determine if there is any loss
  5. Actual firing of laser through fiber assembly
  6. Comparison of test results in steps 4 & 5 against spec sheet to determine conformity
  7. Final visual inspection under 500x microscope
  8. Proper packaging of laser fibers for return to customer

Most common forms of laser fiber damage are listed as follows:

-Operator : Accidentally tripped on laser fiber cable, causing connector head to break

-Over-bending : Optical Fiber cable is bent and causes internal breakage – This leads to the external sheathing to melt as the section of internal fiber optic cable has already broken internally

-Improper Handling : Touching of fiber ends with bare hands in an attempt to “clean” the fiber – This might cause fiber breakage and contamination of fiber ends

Common Brands of Laser Fibers repaired:

Mitsubishi St600F ; Miyachi ; OEM

Common Core Sizes (Large Core laser fibers):

200um; 300um; 400um; 600um; 800um; 1000um

Visit our laser fiber repair page for more information regarding our value added services



Diamond Ice lathe tool | Jewellery News Asia

Admin
Jewellery News Asia Gold Technic Ice Lathe Tool Feature

Jewellery news asia Gold Technic Ice Lathe Tool Feature Dec 2016

Our new customised ice lathe tool is featured on Jewellery News Asia. Aisa’s leading magazine for the jewellery and gem industry.

Ice_Lathe_Tool_Gold_Technic

Our latest product is the custom made ice lathe diamond tool. The ice lathe diamond tool is used in precision cutting of gold chain on the fully automatic multi tool CNC ice lathe. The gold chain is embedded in ice, frozen and positioned onto a spinning drum. As the drum spins, the diamond tool will cut the gold chain leaving behind a very shiny surface. In this method of production, it is crucial that the diamond tool is sharp and precision made to process multiple chain in a single icing session. Each tool is fitted on a multi tool tool head and tools can be changed automatically according to the pre-set program. Up to three diamond tools work simultaneously, removing three times as much material per pass, and there is no downtime due to empty passes.

The consistency of our diamond tools is crucial application on multi tool CNC machine as it reduces machine downtime due to tool failure and variation in tool length and size. All our tool shanks are cnc machined to ensure that tolerance is kept to a minimum of +/-0.01mm.

The quality of the diamond used will affect the lifespan on the lathe tool, therefore, we assure customers that only the best stones are selected to construct the ice lathe tool.

ST600F Laser Fiber repair with D-80LKA type connector

Admin
Laser fiber ST600F damaged

ST600F Laser fibre (damaged)

We receive damage ST600F laser fiber in all types of condition. The above laser delivery fiber is a 600 micron laser fiber (ST600) from a high-power Nd:YAG welding machine.  A contaminated laser delivery fiber can cause the connectors to heat up and eventually burn out.

If not replaced in time, it may also affect the focusing head as the fumes from the burn out may also contaminate the lenses inside the focusing head. Therefore it is important to remove and replace the damage laser delivery fiber once it is identified.

Stages of Assessment ST600F Laser fiber

At the assessment stage, we can see that the 600 micron laser fiber (ST600F) is contaminated with grease and dirt on the edge of the connector and the surface of the fiber core.  There is also a laser burn mark at the edge of the connector and a damaged blurred laser core. There is a lot of contaminants on the sapphire connector surface. We will also check for any visible breakage alongside the laser fiber and make indications before we send the fiber to the servicing department for repair.

At the servicing stage, we terminate the fiber and repolish to restore its original surface. Terminated fiber ends are highly polished for low insertion loss. Aside from reflection losses at each end of the laser delivery fiber, a 3-meter length of cable can transmit 99 % of the laser beam power.

The connector will also be repaired and damaged parts replaced. Gold Technic uses industry standard D-80LKA connectors for quick and easy coupling and decoupling from the focusing heads and laser machine.

After repair the raw fibers are inserted back into a multi-layer protective sheathing
surrounded by a reinforced monocoil jacket that provides both flexibility and tensile support.

Before delivery, we will ensure that all laser fiber are tested and in working order.

Designing precision diamond cutting tools for CNC machining

Admin
Diamond cut gold ball chain on CNC diamond cut machine

Precision cut gold ball chain by CNC diamond tool cutting machine

Precision diamond cutting tool Research and Developemnt

Precision diamond cutting tool can be used to cut metals such as gold, silver, copper and brass. In jewellery manufacturing, gold and silver are most commonly used. It is important to fine tune diamond tools when working on CNC cutting machine to reduce machine downtime and wear and tear of the tools. Maintenance Policy and Procedures of CNC machines and precision diamond tools are also very important in prolonging lifespan of diamond tools. We will elaborate more on recommendations on maintenance policies in our next contribution.

We help our customer troubleshoot to get the perfect precision diamond cut on the ball chain machine. The above picture shows row of ball chain that was cut by a precision diamond cutting tool that failed the cutting test on the first trial run because it cannot produce the perfect crescent/ moon cut on the ball chain. The moon cut was too small and cannot cover the whole surface of the ball. That has resulted in a dull and unfinished ball.

Surface finish on a ball chain can be compared to reflective qualities of diamond when cut in different shape. For example Round brilliant cut, Marquise cut, Oval cut and Princess cut. In this case, it is widely known in the market that the Round brilliant cut brings out the most shine in a diamond. Similarly, with our experience in producing diamond tools, we can recommend the ideal profile to produce the best cut on ball chains.

Precision diamond cutting tool Diagnosis

After our study of the initial problem, the production team redesign the tool and test on the balls again. Finally we could achieve the perfect cut. We complete the development process in about 6-8 weeks and customer was very satisfied with the performance. This shows how important it is to engage the right company to propose the best solutions for all your diamond cutting needs.

Do give us a call or email us for more solutions on precision diamond cutting tools. We will be updating our blog periodically.



Advantages of laser welding vs traditional torch soldering

Admin
Laser weld samples

Advantages of laser welding

There are many advantages of using laser welder in jewellery repair as compared to traditional torch soldering.

Soldering is a capillary fill system where solder is heated with a gas-oxygen torch or open flame.  The solder then flows across and fill up the gap.  The heat used for this process is very high, and often results in a visible dark seam or discoloration in the solder area. When soldering with a torch, the heat is applied to a relatively large area resulting in heat transfer. If the user is not careful, he can burn or destroy heat sensitive stones and other heat sensitive materials that are in close proximity to the flame.

Laser stands for Light Amplification by Stimulated Emission of Radiation. Laser welding is a non-contact process in which light energy is used to weld the precious metals to themselves. The heat used in the laser welding process very localized. After welding, it results in a seamless, undetectable work zone that is not discolored in any way.

During the laser welding process, the metal adjacent to the welding point does not melt.  This precision heat source allows the user to laser weld metal in close proximity of heat sensitive stones and without affecting the stone or material.  Because of this focused heat source, the laser weld will not anneal springs or clips eliminating the need to replace damaged findings.

When using a laser welder, the beam is so concentrated, it burns away any impurities during the laser welding process, thus eliminating the need for prior cleaning or coating. Laser welding can be performed on dirty or even tarnished surfaces without leaving discoloration or dark markings.

Laser Yag Rod Refurbishing & Optical Repair

Admin

Laser rod repair

Reconditioning optical components is another of our repair capabilities. Each year, we resurface hundreds of laser rods and laser rod assemblies to like-new condition. Reconditioning laser rods and assemblies can save you hundreds to thousands of dollars over the new purchase price.

With over 20 years laser related experience, Gold Technic offers you the best possible source for laser service, laser repairs, laser components, and system upgrades.

Tips when using your laser optical fiber

Admin
Laser optical fibers

Laser optical fibers – Gold Technic

Proper Laser optical fiber alignment for your laser machine ensures optimum performance. It is important not to bend the fiber beyond the minimum bending radius and keep the focusing head clean, free from oil and dirt. Poor fiber handling can cause damage to the laser fiber and the fiber head to burn out. So it is important that the technicians are well informed about the laser operations before operating the machines.

New Laser Fibre Supply

Laser Fibre SizeLengthConnector Type
300 micron3m/ 5m/ OthersD80 compatible
400 micron3m/ 5m/ OthersD80 compatible
600 micron3m/ 5m/ OthersD80 compatible
800 micron3m/ 5m/ OthersD80 compatible
Other sizesPlease EnquirePlease Enquire

Best working practice is to route the fiber above ground, not touching the floor between the laser and workstation to avoid the possibility of crushing the fiber, then coil and hang excess fiber length at the workstation. Coiling the fiber above ground can also avoid accidental tripping and prevents dirt getting trapped on the outer fiber sheathing.

If the laser focus head will be moving, give sufficient slack, and again make sure the fiber’s connection to the focus head avoids exceeding the minimum bend radius.
