Diamond Pins

Introduction

The UK StarDuster 800M is primarily used to create a soft, paved, shiny look on jewelry pieces. Each
pen is precision constructed out of top-grade stainless steel that is rust-free and comfortable to use over
extended period of time. Usage of the UK StarDuster 800M is not limited to the jewelry industry. It can
also be used as a simple engraving tool for hobbyist, watchmakers, and anyone who needs an excellent
engraving pen for their application.

Advantages of UK StarDuster 800M

• Designed to produce minimal vibration for extended periods of usage.
• Adjustable speeds and interchangeable diamond pins to let users create the ideal design
• Fully hardened diamond pins and sleeve for long working life.

Applications

Recommended for working with Gold, Silver, Copper, and Platinum.

Some examples of applications are listed below:

Excellent outlook For delicate surfaces, use the springs provided in the UK StarDuster 800M set to lighten the pressure of each punch, leaving a smooth velvet surface on rings and accessories.
Smooth texture To achieve a different texture, there are 5 types of diamond pins to choose from. Each type is specially set to cater to your needs. 1. Model “J” – For large surfaces 2. Model “NJ” – For small/delicate surfaces 3. Model “BJ” – Fitted with a bigger diamond tip for long life 4. Model “BNJ”- Fitted with a bigger diamond tip for long life 5. Model “S” – For a coarse finished texture
Optimal Shine Dust on small balls to give a “frosted” shiny appearance. Use our Model “S” pins to enhance the shiny effect.

Complete set includes:

1 x UK Star Duster 800M pen
1 x Quick Coupling
Diamond pin
1 x Model “J”
1 x Model “NJ”
1 x Nozzle Key
1 x Blue Air tu

Operating manual for UK StarDuster 800M

Please read and understand before the operation.

Quality Assurance

Each UK StarDuster 800M™ pen and the diamond pins are put through stringent quality tests to ensure
that they meet the quality requirements. The UK StarDuster 800M™ set is guaranteed to conform to the
operational requirements.

Inspection

When unpacking, please check for the following items:
1. Visually inspect if there is any damage to the UK StarDuster 800M™ and its parts caused by
transportation.
2. Check for any looseness or for any disconnection of parts.
Note: Should you notice any trouble or damage with the UK StarDuster 800M™ or its accessories, please feel free to contact
us.

Assembly

I. Installation of a Quick Coupling between the air compressor and the UK StarDuster
800M™
The airline must be fitted with a pressure regulator and a water filter (not included in the set) for longer
service and to avoid jamming/damage to equipment.
Water in the air line will cause damage to the UK StarDuster 800M™. Water must be fully eliminated for
the air supply to avoid corrosion inside the UK StarDuster 800M™. Drain the air tank and line daily or as
often as necessary, depending on weather and temperature conditions.

Operation

Re-examine prescribed installations once more before operating the UK StarDuster 800M™. Please
operate the equipment in accordance with the following procedures to obtain the specific performance of the
UK StarDuster 800M™.
1. Connect parts as shown in the assembly section.
2. Turn on the air compressor to 25PSI to test the equipment.
3. Gradually increase the PSI to 30 to obtain the best results.
4. For best performance, the UK StarDuster 800M™ is recommended to be used with high quality
air compressor and original Model “J” and Model “NJ” diamond pins.
For first-time users, it is recommended that you make test trials using the UK StarDuster 800M™
to familiarize oneself with its operation.

Technical characteristics

• PSI Pound per square inch
• Maximum PSI 30PSI
• Minimum PSI 25PSI

Operating requirement

1. A set of UK StarDuster 800M™
2. Air compressor fitted with pressure regulator and water filter with Speeds of PSI 25 to 30.

Accessories

Safety instructions:

1. Before handling and using the UK StarDuster 800M™, thoroughly familiarize yourself with
necessary safety precautions
2. We would recommend users to put on safety goggles when using the UK StarDuster 800M™.
3. Do not touch the tip of the UK StarDuster 800M™ with your bare hands when in operation.
4. Do not look or point the diamond pin at yourself or others when in operation.
5. Do not operate UK StarDuster 800M™ over 35PSI.
6. Higher pressure will cause excessive wear on the UK StarDuster 800M™‘s internal parts and
shorten its life.
7. Please disconnect the UK StarDuster 800M™ from the air compressor when not in use.
8. Do not use on tough surfaces.
9. Maintain the equipment in a safe working condition. Service the UK StarDuster 800M™ regularly
to prevent faulty operation and rectify any faults promptly.
10. If the problem cannot be rectified, be sure to get in touch with us immediately.

Please note that failure to conform to the safety instructions might result in serious injuries. Failure to conform to the
recommended range of PSI will result in the malfunction of the equipment. Higher pressure is not desirable as it may cause damage tothe
internal parts of the UK star duster 800M.

Finally, we would like to thank you for choosing the UK StarDuster 800M™. We hope that you will enjoy using it
as much as we do to serve you as our customer. Please feel free to contact us for further inquiries.
